Our pristine analog 14-channel USB-C compatible audio interface, analog mixer, and stereo SD recorder.
Verfügbarkeit für Abholungen konnte nicht geladen werden
StudioLive® AR12c Analog Mixer
Normaler Preis
€599,00
Normaler Preis
€599,00
Verkaufspreis
€599,00
Stückpreis
pro
Übersicht
Der StudioLive® AR12c sieht zwar aus wie ein gewöhnlicher Analogmischer, wurde aber speziell für das Recording entwickelt. Mit einem erstklassigen analogen Frontend, acht XMAX Mikrofonvorverstärkern mit hohen Verstärkungsreserven und 14x4 Audio-Interface mit 24 Bit und 96 kHz ermöglicht das Hybrid-Design die einfache Aufnahme von Studioproduktionen sowie die Mischung von Live-Shows über eine einzige, intuitive Konsole. Mit weiteren Merkmalen wie einem musikalischen 3-Band-Analog-EQ, Mic/Line-Boost für pegelschwache Vintage-Synthesizer und Broadcast-Mikrofone, einer brandneuen digitalen Effektsektion mit satten Reverbs und üppigen Delays, Bluetooth-Technologie, einem stereophonen SD-Recorder etc. präsentiert er sich als leistungsfähiges, modernes Aufnahmesystem für die Produktion von Musik und digitalen Inhalten.
Das integrierte Audio-Interface des StudioLive Ar12c ermöglicht die Aufnahme aller 12 Eingänge sowie der Gesamtmischung und verfügt über zwei Stereo-Playback-Streams zum Einspielen von zuvor aufgenommenen Spuren, Soundeffekten, Loopback-Audio und weiteren Quellen. Vier preisgekrönte PreSonus XMAX Mikrofonvorverstärker bieten die nötigen Gain-Reserven, um selbst die subtilsten Details zu übertragen. Das analoge Mischpult-Frontend erlaubt den intuitiven Anschluss Ihrer Geräte. Mit seinem USB-C-kompatiblen Anschluss ist Ihr StudioLive AR12c mit nahezu jedem Computer nutzbar.
Sie möchten unterwegs aufnehmen? Mit dem SD-Recorder des StudioLive Ar12c ist das kein Problem. Setzen Sie einfach eine SD/SDHC-Karte ein und schon können Sie Ihre Summenmischung aufnehmen – perfekt für Live-Shows, Interviews und Bandproben.
Dank flexibler Aufnahmeoptionen, einer Vielzahl von Anschlüssen und seinem intuitiven Arbeitsablauf ist das StudioLive Ar12c ein besonders unkompliziertes Aufnahme- und Mischsystem.
Overview
Merkmale
- 14x4 24-bit/96 kHz, USB 2.0 (over USB-C™ connection) audio recording interface; record every channel plus the main mix
- 2x2 SD recorder (record main mix); supports SD and SDHC formats up to 32 GB
- 14-channel analog mixer with:
- 8 balanced microphone inputs with XMAX mic preamps plus two instrument inputs, 12 balanced line level inputs, and 2 insert points
- Stereo Super Channel (Ch. 13/14) with Bluetooth®0 wireless, RCA inputs, 1/8-inch stereo input, and switchable SD/USB stereo playback
- Stereo effects processor with 16 presets, dedicated send and return, and bypass footswitch jack
- Complete recording solution: Includes Capture™ live-recording software and Studio One® Pro+ for Mac® and Windows
Downloads
Das Gesuchte nicht gefunden?
Melde dich bei deinem my.presonus.com-Konto an.
Documentation
Software
Das Gesuchte nicht gefunden?
Melde dich bei deinem my.presonus.com-Konto an.
Downloads
Onboard effects.
The StudioLive AR12c mixer’s onboard effects processor lets you add high-quality reverb, delay, or chorus to any channel for a professional monitor mix. Like what you hear in your headphones? Record the main mix and capture the effects mix, too—with or without the dry channels—to blend with your multitrack recording. Experiment in post-production to your heart's content.
One-click recording
The StudioLive AR12c is tightly integrated with PreSonus® Capture® live-recording software. Capture is designed to make recording easy by instantly configuring with your mixer and allowing you to record every channel plus the main mix with a single mouse click. Even better, your Capture sessions open natively in Studio One!
Studio One Pro 7 DAW Software Access Included.
Your hardware registration includes a 6-month stackable membership to Studio One Pro+ featuring unlimited access to the latest version of Studio One Pro and all the extras.
Spezifikationen
Elektronik
Phantom Power
+48 VDC
Signal Level Led
Signal: -30 dBFS (Pre-EQ) Clip: -3.0 dB Before Clip (Pre or Post-EQ)
Voltage
220-240V UK
Allgemein
Color
Blue
Product Name
StudioLive® AR12c Analog Mixer, Blue, 230-240V UK
Series
StudioLive®
Hardware
Digital Audio USB Recording Port
USB 2.0
Eingaben
Instrument Input Connection Type
1/4” TS Female, Unbalanced, Hi-Z
Instrument Inputs Dynamic Range
> 108 dB (Mid Gain, Unweighted)
Instrument Inputs Frequency Response
20 Hz to 20 kHz, +0.5/-1.5 dB
Instrument Inputs Gain Range
43 dB, ±1 dB (+12 to +55 dB)
Instrument Inputs Maximum Level
+9 dBu ±1.0 dB (Minimum Gain, 1 kHz@0.5% THD + N)
Line Input Connection Type
1/4" TRS, Balanced
Line Inputs Frequency Response
20 Hz to 20 kHz, +0.5/-1.5 dB
Line Inputs Gain Range
Mono: 40 dB, ± 1 dB, Stereo: 0 dB or 10 dB
Line Inputs Impedance
10 kΩ (Balanced)
Line Inputs Maximum Level
+26 dBu ±1.0 dB (Minimum Gain, 1 kHz@0.5% THD + N)
Line Inputs Signal To Noise Ratio
85 dB (+4 dBu)
Line Inputs Total Harmonic Distortion
<0.01% (1 kHz, -1 dBFS, A-Weighted)
Microphone Preamp Common Mode Rejection Ratio
65 dB (1 kHz, +55 dB Gain)
Microphone Preamp Equivalent Input Noise
<128 dBu
Microphone Preamp Frequency Response
20 Hz to 20 kHz, +0.5/-1.5 dB
Microphone Preamp Gain Control Range
43 dB (+12 to +55 dB)
Microphone Preamp Input Impedance
1 kΩ
Microphone Preamp Maximum Input Level
+9 dBu ± 1.0 dB (Unity Gain)
Microphone Preamp Signal To Noise Ratio
94 dB (+4 dBu)
Microphone Preamp Total Harmonic Distortion
<0.01% (Minimum Gain, A-Weighted)
Measurements
Media Storage Capacity
SD Card: 2 GB; SDHC Card: 32 GB
Product Depth
15.56" (397 mm)
Product Height
3.5” (90 mm)
Product Width
15" (381mm)
Verschiedenes
Commodity Code
8543709099
Power Cable
IEC
Recommended Ambient Operating Temperature
0˚ to 40˚ Celsius / 32˚ to 104˚ Fahrenheit
Recording File Format
Stereo WAV
Supported Media Format
FAT16 Formatted SD™ Card, FAT32 Formatted SDHC™ Card
Supported Sample Rates
44.1, 48, 88.2, 96 kHz
Output
Headphone Outputs Dynamic Range
>103 dB (A-Weighted)
Headphone Outputs Frequency Response
20 Hz to 20 kHz, +0.5/-1.5 dB
Headphone Outputs Maximum Output
150 mW /Channel at 60 Ω
Headphone Outputs Total Harmonic Distortion
<0.01% (Bandwidth 20 Hz - 20 kHz, -1 dBFS, Unweighted)
Line Outputs Connection Type
1/4" TRS, Balanced
Line Outputs Maximum Output Level
+18 dBu
Line Outputs Output Impedance
100 Ohms
Main And Line Outputs Dynamic Range
>108 dB (A-wtd)
Main And Line Outputs Frequency Response
20 Hz to 20 kHz, +0.5/-1.5 dB
Main And Line Outputs Total Harmonic Distortion
<0.01% (Bandwidth 20 Hz - 20 kHz, -1 dBFS, Unweighted)
XLR Outputs Maximum Output Level
+24 dBu, ±1.0 dB
XLR Outputs Output Impedance
100 Ohms
Leistung
Crosstalk (Adjacent Channels)
-85 dBu (Reference = +4 dBu, 20 Hz to 20 kHz, Unweighted)
Digital Audio Bit Depth
24
Digital Audio Dynamic Range
105 dB (A-Weighted, 48 kHz)
SD Recorder Bit Depth
Recording: 24 Bit, Playback: 16 or 24 Bit
SD Recorder Sampling Rate
44.1 kHz
